The Worldpay Gateway
Worldpay is one of the payment gateways you can use in Engaging Networks to process donations and payments.
This document contains details for setting up the Worldpay gateway in Engaging Networks.
We can integrate with two types of Worldpay gateway:
Worldpay Corporate gateway (formerly known as the Global Gateway). This can process recurring card payments. You will also need to enable IP addresses for the integration to work – see below
Worldpay Business gateway. This cannot process recurring card payments. You will need to also have an Installation ID for this to work – see below
Before setting up the gateway
1) Arrange a merchant account with Worldpay
Before creating Worldpay donation pages, you will need to have arranged your merchant account with Worldpay. We recommend having a Live and a Test version.
2) Ensure you have a Base URL for donation pages
If you haven’t already got a Base URL (subdomain) for your donation pages, please contact the Support team. This needs to be entered into the Account Preferences’ “Donation Base URL” which can be accessed via the Hello > Account settings > Account preferences menu.
3) Tell WorldPay to enable “Invisible XML” on your account
Invisible XML needs to be enabled before our integration can work. Contact Worldpay Support to set this up.
4) Enable IP addresses [Corporate Gateway accounts only]
In addition, you will need to log into your merchant account using the Worldpay interface and enable the IP addresses for both the Test and Live versions of the gateway (this applies to Corporate Gateway accounts only):
3.19.5.96
3.140.123.11
3.97.146.169
15.222.229.212
3.138.251.155
3.22.198.2355) Find the Worldpay credentials needed to set up the gateway in Engaging Networks
You will need the following credentials in order to link to your gateway. You can find these from within your Worldpay dashboard:
Worldpay merchant code
XML password
Installation ID [Business gateway only]
The XML password differs from the password you use to log into your merchant account.
For clients in the UK or Europe, or those that wish to take donations from supporters in those locations, you will also need to get additional credentials to set up 3DS2 which enables an additional authorisation step to display so that the supporter can securely authorise their donation, for example via a code sent to their mobile device.
Contact your Worldpay representative and ask them to provide you with these Cardinal Commerce credentials to set up 3DS Flex (Direct):
API Key
API Key ID
Org Unit ID
Setting up the Worldpay gateway in Engaging Networks
It is recommended that you create and keep two separate gateway records in your account, one for testing and one linked to your live gateway. Donation pages should be linked to a test gateway initially, and then switched to a live gateway before launch. To create each one:
Go to Hello YOURNAME > Account Settings > Gateways
Click New Payment Gateway to create a new entry
Add information to the fields:
Field | Description |
|---|---|
Reference name | A unique name for the gateway. It is a good idea for the name to include the type of gateway (eg. Worldpay corporate gateway), the currency (if applicable), and whether it is a live or test gateway. |
Select gateway | Choose “Worldpay” |
Username | Enter your Worldpay Merchant Code in capital letters |
XML Password | Enter your XML password The XML password is set in the merchant gateway, it is not the password to log into your merchant account. The two passwords are different. |
Installation ID | [Corporate Gateway only]. Enter your Installation ID here. Leave blank for the Business Gateway |
Enable 3D | Tick this if you want to use 3DS2 which is needed for supporters in the UK and Europe. This will enable an additional three fields. |
API Key | [Enable 3D only]. Add the API Key given to you by Worldpay. |
API Key ID | [Enable 3D only]. Add the API Key ID given to you by Worldpay. |
Org Unit ID | [Enable 3D only]. Add the Org Unit ID given to you by Worldpay. |
Test gateway | Should be checked for a test gateway, must be unchecked for a gateway that will accept live donations. |
Save the gateway. Repeat so you have one Gateway for Live payments, and one for Test
Anyone within the merchant’s organization who has access to the merchant interface can change the xml password. WorldPay does not have access to the merchant’s passwords and can only assign new passwords, rendering the current password inoperable.
Enabling fields to take donations using the Worldpay gateway in Engaging Networks
The following fields need to be set up in the Account Data Structure and then added to a form block in your page using page-builder.
You may already have some of these fields in your account, in which case you need not add them.
Basic required fields for credit/debit card single payments
Field | Default input type | Comments |
|---|---|---|
Email Address | Text | Email address identifying the supporter record |
Credit Card Holder | Text | Card holder name exactly on card |
Credit Card Number | Token | Credit card number w/o spaces |
Payment Type | Select | If the page is configured to only accept credit cards this is optional. Credit cards = CreditCard (the specific type will be detected on the form and captured with the transaction ) |
Payment Currency | Select for multiple currencies, or Hidden for a single currency | This will contain the three letter ISO-4217 currency code, eg. GBP for pounds sterling. N.B. If you are only accepting a single currency, you must still have this on the page in your form block, but there is no need to display the field to supporters. It can be set as a “Hidden” field. |
Credit Card | Split select | Format must be MM/YYYY. It is recommended that you use the ‘split select’ field type, so that one field holds the month (01 to 12) and the other the year (2022 onwards). In page-builder, it should have a delimiter of /. See below for details. |
Credit Card | Token | The additional Card Verification Value printed on |
Donation Amount | Text if you don’t want to give options. Radio with input for set amounts & an Other option. | May be entered as a whole number, or with two decimal places. Eg. Twelve dollars may be entered as ’12’ or ‘12.00’. You may want to consider using the ‘select with input’ or ‘radio with input’ field types. |
Additional fields required for Worldpay Corporate Gateway recurring payments
A recurring payment page is built in exactly the same way as a single payment pages, but with the addition of several fields specific to recurring payments:
We can only process recurring payments for the Worldpay Corporate Gateway (formerly known as the Global Gateway), not the Business Gateway. The initial payment is processed in the same way as a single payment, and then subsequent payments are requested automatically by Engaging Networks at the defined interval. You can manage recurring payments via the ‘Manage Supporters’ page in the client dashboard.
Field Name & Field Tag | Default input type | Description |
|---|---|---|
Recurring Payment | Radio or Select | Submitting “Y” will flag the transaction as a recurring payment. Any other value, e.g. “N”, will result in a single payment. You can set this up as a radio with labels of “Recurring” and “One-off” with values of “Y” and “N” respectively. |
Recurring Frequency | Radio or Select | Permitted values are MONTHLY, QUARTERLY, SEMI_ANNUAL and ANNUAL. Please see the notes below on ‘select’ field types for details of ways of presenting these fields to supporters. If you only wanted to take monthly payments, you could set this up as a Hidden field with a default value of MONTHLY in page-builder. |
Recurring Day | Hidden or Select | The day of the month on which the recurring payment should be taken. If left blank as a Hidden field, this will use today’s day so that subsequent payments are taken on the same day as the initial payment every month. |
Recurring End Date (optional) | Numeric | When this recurring payment should cease. The value must be in the format DD/MM/YY |
Other optional fields you may want to include
It is strongly recommended you include name and address fields on your donation page for added fraud protection, since Worldpay can use these to match the card details and determine whether the donation is valid.
Field Name & Field Tag | Default input type | Description |
|---|---|---|
Issue number | Text | This field must be displayed if you are potentially accepting donations from debit cards, but should not be made mandatory as not all debit cards have an issue number. It is possible to use ‘form dependencies’ to dynamically hide or show this field depending on the card type selected. Please contact us for help setting up this feature. |
First name and last name | Text | The supporter’s first/last name (as opposed to cardholder name) |
Address 1 | Alphanumeric | The street address of the cardholder. If this field is submitted, both postal code and country must also be submitted. |
Postal code | Alphanumeric | The postcode of the cardholder. If this field is submitted, both address 1 and country must also be submitted. |
Country | Alpha | The cardholder’s country. This must be submitted in upper case two-letter ISO-3166 format (for example “GB” for the United Kingdom). If this field is submitted, both postal code and address 1 must also be submitted. |
Testing donation pages
Provided that you are using a gateway set up in test mode, you can use the following card details during the testing process. All other form fields may take any value, as long as expiry date is set to some time in the future.
Card scheme | Card numbers |
|---|---|
Maestro | 6759649826438453 (this card has no issue number but uses a start date) |
Visa | 4111111111111111 |
Amex | 34343434343434 |
Ecmc | 5555555555554444 |
Diners | 36148900647913 |
Dankort | 5019717010103742 |
Airplus | 122000000000003 |
Laser | 630490017740292441 |
Cb/Cartebleue | 5555555555554444 |
You can check orders after submitting the test transaction by logging into your merchant account with Worldpay and switching to the test environment.
